臺灣KOMPASS康百世朝田VD1/VB1/VA1-30/20-FA3/FA2/FA1

液壓元件的基本參數及分類

帶大家來了解下液壓元件的基本參數和分類。

液壓元件的工作能力由其機能參數決定，液壓元件的基本參數與液壓元件的種類有關，不同的液壓元件具有不同的機能參數，其共性的參數與壓力和流量相關。

(1)公稱壓力

公稱壓力是標志液壓元件承載能力大小的參數。液壓元件的公稱壓力指其在額定工作狀態下的名義壓力，液壓元件的公稱壓力單位爲MPa (10Pa)。

(2)公稱流量

公稱流量是標志液壓元件暢通流暢機能的參數，公稱流量是指液壓閥在額定工作狀態下通過的名義流量，常用單位爲L/min。

公稱壓力、公稱流量一般在液壓元件或液壓系統的銘牌上已經表示出來，使用液壓元件時，工作壓力和通過液壓元件的流量不要超過其公稱壓力和公稱流量。

液壓元件分類

動力元件- 齒輪泵、葉片泵、柱塞泵、螺桿泵等。

執行元件-液壓缸：活塞液壓缸、柱塞液壓缸、擺動液壓缸、組合液壓缸

液壓馬達：齒輪式液壓馬達、葉片液壓馬達、柱塞液壓馬達。

控制元件-方向控制閥：單向閥、換向閥

壓力控制閥：溢流閥、減壓閥、順序閥、壓力繼電器等

流量控制閥：節流閥、調速閥、分流閥。

輔助元件-蓄能器、過濾器、冷卻器、加熱器、油管、管接頭、油箱、壓力計、流量計、密封裝置等。

液壓閥己達到幾百個品種上千個規格，從不同角度分析液壓閥有不同分類方式:按用途可分爲方向控制閥、壓力控制閥、流量控制閥;按連接方式分爲管式連接閥、闆式連接閥、法蘭式連接閥，目前還泛起了疊加式連接閥、插裝式連接閥:按工作原理可分爲通斷式元件、比例式元件和伺服式元件:按組合程度可分爲單一閥和組合閥等。
